Musical Fidelity M6 Vinyl MM/MC Phono Preamplifier (Silver)

The M6 Vinyl is a
very high performance, fully balanced, highly accurate phono MM/MC cartridge
amplifier in a beautifully designed and executed casework. The unit features
three separate, independently selectable cartridge inputs. This allows choice
between three different turntables, or multiple tone arm configurations if
required. Selectable gain is provided to allow for different cartridge
sensitivities and to suit any equipment. Cartridge type and loading is selected
by front selector buttons for optimum cartridge performance.

The M6 Vinyl also
includes ourrenowned RIAA correction that offers extremely accurate resultsto
beyond 80kHz. That may sound extreme, but there is a good deal of information
above 20 kHz that needs correction. If it isn’t corrected, it will show itself
as ringing and overshoot. With both extraordinarily low noise and exceptional
overload margin the M6 Vinyl can comfortably handle even the most demanding of
cartridges and satisfy the most discerning of listeners.

Cartridge type:	MM MC
Type:	Transistor
THD:	<0.01%
Frequency Response:	RIAA RIAA/IEC
MM output voltage:	300mV
MM input voltage :	2.5mV
MC input voltage:	250μV
MC output voltage:	300mV
MM input impedance:	47.000 Ohm
MC input impedance:	25 Ohm
MM signal / noise ratio:	>90dB
MC signal / noise ratio:	>88dB
USB output:	NO
2xRCA line outputs:	1
2xRCA line inputs:	3
2xXLR outputs:	1
OTHERS:	overload margin: 31dB (for MM and MC cartridges)
::	state of art SMD technology
::	fully isolated inputs allow for switching for aup to 3 turntables at once
::	adjustable input impedance on MC whilst it is playing
::	adjustable capacitance on MM whilst it is playing
Power consumption:	<0.5W standby 20W maximum
Height:	10cm (4 inch.)
Width:	44cm
Depth:	38.5cm
Weight:	5.5kg
