DS Audio DS Master3 Phono Stage/Equalizer For Optical Cartridge

DS Master3

The successor to DS Master1, which has created the history
of DS Audio

Equalizer

Dual monaural circuit design with three transformers and
six selectable output patterns

The DS Master3 equalizer is a dual monaural circuit design
with three transformers and completely independent Lch and Rch circuits. The
power supply has been overwhelmingly strengthened to enable deeper and richer
low-frequency expression. The DS Master3 equalizer has balanced and unbalanced
outputs, and the low-frequency cutoff frequency can be selected from six
different options.

Hand-made in Japan circuit board

Every component part used in our products is tested and
evaluated by our expert Japanese technicians.

In addition to using a specially printed circuit board, twist-connection of the
component legs is further evidence of DS Audio’s excellent attention to detail.

Each and every product is hand-made and quality assured by our skilled
engineers.

DS Master3 Equalizer for Optical Cartridge

Output voltage
700mV(1kHz)

Output impedance
RCA 120Ω XLR 120Ω

Pre amp input impedance
More than 10kΩ

Input terminal
RCA terminal

Output terminal
RCA terminal×3, XLR terminal×3

Size
W45.2cm×H15.3cm×D48.4cm

Weight
23kg
